External Cladding Installation
Installation of external wall cladding systems for residential and commercial construction including fibre cement sheet (James Hardie, BGC), weatherboard (timber and composite), and sheet metal cladding. Covers controls for respirable crystalline silica from fibre cement cutting (wet cutting mandatory since 1 September 2024), falls from scaffolding, nail gun injuries, circular saw kickback, manual handling of long sheets in wind, falling objects from scaffold, and UV/heat exposure. Cladding installed over building wrap/sarking to completed wall framing per AS 1684 and manufacturer specifications. Pre-filled hazards, controls, and risk ratings.
What's In Your SWMS
7 Hazards & Controls
Fractures, spinal injuries, head injuries, internal injuries, death
Install as much cladding as possible from ground level before erecting upper scaffold lifts. Pre-cut all materials at ground level cutting station.
Use scaffolding with full guardrail system instead of ladders for all cladding work above 2m. Consider EWP (elevated work platform) for short-duration access.
Establish exclusion zone at ground level below scaffold. No workers below without hard hats.
- Scaffolding erected to AS/NZS 1576 with guardrails (900-1100mm), mid-rails, and 150mm toe boards
- Scaffold boards secured and platform minimum 450mm wide
- Internal scaffold face maximum 225mm gap from wall (prevent falls between scaffold and building)
- Scaffold access ladder secured at top and bottom, extending 1m above platform
- Fall arrest system (AS/NZS 1891) where scaffold guardrails insufficient
- Tool lanyards for all hand tools used at height
- All workers at height must hold current Working at Heights training (RIIWHS204E)
- Inspect scaffolding daily before use - check all connections, guardrails, boards, and base plates
- Do not work on scaffold in wind gusts exceeding 30 km/h (large sheet handling) or 40 km/h (general)
- Three-point contact when ascending/descending scaffold ladders
- Do not lean beyond scaffold guardrails - reposition scaffold or use reach tools
- Maximum two workers per scaffold bay when handling large sheets
- Plan rescue procedure before commencing work at height
- Licensed scaffolder to erect, modify, and dismantle scaffold over 4m
Full body harness (AS/NZS 1891) where required. Hard hat. Non-slip safety footwear.
15-Step Work Procedure
Equipment & PPE
Equipment (14)
- Pneumatic cladding nailer / fibre cement gun
Purpose-built for fibre cement or cladding applications. Sequential trigger only. Stainless steel or galvanised nails to prevent corrosion staining. Check manufacturer fixing specifications.
- Air compressor and hoses
Appropriate capacity for cladding nailer. Drain moisture daily. Position at ground level - run hose up scaffold. Safety valve functioning.
- Circular saw with dust extraction attachment
For timber weatherboard and framing cuts. Blade guard functioning. Riving knife in place. NOT to be used for dry cutting fibre cement (silica hazard).
- Electric fibre cement shears / guillotine
Preferred low-dust cutting method for straight fibre cement cuts. Produces minimal RCS compared to power saws. Use where practicable before resorting to wet cutting with saw.
- Wet cutting station (continuous water supply and collection)
MANDATORY for any power saw cutting of fibre cement since 1 September 2024. Continuous water to blade. Slurry collection tray. Water supply via hose or pressurised bottle. Set up at ground level away from scaffold.
- Scaffolding with guardrails, mid-rails, and toe boards
Erected to AS/NZS 1576 by licensed scaffolder (over 4m). Full guardrail system: top rail 900-1100mm, mid-rail, 150mm toe board. Platform minimum 450mm wide. Scaffold boards secured.
- Extension ladder and step ladder
Industrial rating (120kg minimum). Extend 1m above landing. Secured at top. 4:1 angle ratio. For scaffold access only - not as a work platform for cladding.
- Spirit level (1200mm) and laser level
For checking level of cladding courses and plumb of vertical joints. Laser level for establishing datum lines across long walls.
- Tape measures (8m) and marking tools
For measuring and marking cladding sheets and weatherboards. Pencil marking only on fibre cement (no scoring).
- Electric drill/driver (cordless)
For screw-fixing cladding where specified by manufacturer. Pre-drill fibre cement to prevent cracking. Countersink attachment.
- Caulking gun and exterior sealant
Exterior-grade paintable sealant for joints, penetrations, and flashings. Check manufacturer-approved sealant type.
- Extension leads with RCD protection
Heavy-duty construction leads. RCD protected (max 30mA). Test and tag current. Keep clear of wet cutting area and water.
- HEPA vacuum / M-class dust extractor
For cleanup of fibre cement dust and debris. HEPA filtration mandatory for silica-containing dust. No dry sweeping of fibre cement dust.
- First aid kit
Include wound dressings for penetrating injuries, eye wash (for dust exposure), burn treatment, and splinter removal tools.
PPE (7)
- P2/N95 respirator (silica rated)AS/NZS 1716
MANDATORY during all fibre cement cutting, sanding, or drilling operations. Fit-tested. Replace when breathing resistance increases. Half-face minimum; full-face respirator for prolonged cutting.
- Safety glasses (impact rated)AS/NZS 1337
MANDATORY during all cutting, nailing, and drilling. Impact rated for nail ricochet and fibre cement chip protection. Wrap-around style to prevent dust entry from sides.
- Hearing protection (Class 5)AS/NZS 1270
Required during nail gun, circular saw, and fibre cement shear operation. Impulse noise from nail guns can cause instant hearing damage.
- Safety footwear (steel cap, puncture-resistant sole)AS/NZS 2210.3
Steel cap for dropped sheets and tools. Puncture-resistant sole for nail penetration. Non-slip sole for scaffold platform work.
- Hard hatAS/NZS 1801
Required when working below scaffold (falling objects risk), during material hoisting, and when other trades working overhead.
- Work gloves (cut-resistant)AS/NZS 2161
Cut-resistant for handling fibre cement sheets (sharp edges) and metal flashings. Remove when operating circular saw to prevent entanglement.
- Sun protection (hat, long sleeves, sunscreen)
Wide-brim hat or hard hat with brim and neck flap. Long-sleeved UPF 50+ shirt. SPF 50+ sunscreen every 2 hours. UV-rated safety glasses.
Training & Emergency
Competency Requirements
- Construction Induction Card (White Card)training
Required for all workers on construction sites. CPCCWHS1001.
- Carpentry / Building Contractor Licencelicence
Required in all Australian states for carpentry and cladding work. NSW: required for work over $5,000. Underpinned by Certificate III in Carpentry (CPC30220).
- Certificate III in Carpentry (CPC30220)certificate
Nationally recognised trade qualification. Includes CPCCCA3024A - Install and Finish Exterior Cladding. Covers all cladding types and fixing methods.
- Working at Heights Training (RIIWHS204E)training
Required for all workers working above 2m on scaffold. Covers fall prevention, harness use, scaffold safety, and rescue procedures. Refresh every 2-3 years.
- Silica Dust Awareness Trainingtraining
Required for workers cutting fibre cement products. Covers RCS health effects, wet cutting requirements, RPE selection, and health monitoring. Mandatory under strengthened silica regulations from 1 September 2024.
- Nail Gun Safe Operation Trainingtraining
All nail gun operators must receive training covering safe operation, trigger types, PPE, and malfunction procedures. Apprentices may only use under direct supervision.
- First Aid Certificate
Recommended for at least one team member. HLTAID011 Provide First Aid. Critical given fall and penetrating wound risks.
- Scaffold User Awareness Training
Required for workers using scaffold. Covers safe access, daily inspection, load limits, and reporting defects. Scaffold erection requires licensed scaffolder.
Emergency Procedures
FALL FROM SCAFFOLD: Do NOT move patient if spinal injury suspected. Call 000. If harness arrest has occurred, rescue from suspension within 15 minutes (suspension trauma risk). Administer first aid for fractures.
NAIL GUN PENETRATING WOUND: Do NOT remove embedded nail. Stabilise nail in position. Apply pressure around wound. If nail has penetrated chest, abdomen, or head - call 000 immediately as life-threatening emergency.
SILICA DUST OVEREXPOSURE: If worker experiences coughing, difficulty breathing, or chest tightness during fibre cement cutting: move to fresh air immediately. Remove contaminated clothing. Seek medical attention. Report exposure for health monitoring records.
HEAT STROKE: Call 000 immediately. Move person to shade. Remove excess clothing. Cool rapidly with water and ice packs to neck, armpits, and groin. Do not give fluids if confused or unconscious.
OBJECT FALLEN FROM SCAFFOLD: Secure scene. Administer first aid to injured worker. If head injury suspected, do NOT remove hard hat. Call 000 for serious injury. Quarantine scaffold section and investigate.
Everything above, included in your SWMS document.
Get This TemplateWriting a SWMS from scratch?
That's 2-4 hours of research, formatting, and compliance checking.
We've already done it — pick your template and download.
Or just do this:
- Unlimited documents
- All 70+ templates
- Instant PDF & DOCX
- Cancel anytime
High-Risk Construction Work Categories
Under Australian WHS Regulations (Section 291 - High Risk Construction Work; Chapter 6 Part 6.5 - Falls; Chapter 7 Part 7.2 - Noise; Chapter 7 Part 7.1 - Hazardous Chemicals (Silica)), this work is classified as high-risk due to:
- Risk of falling more than 2 metres (Cladding installation on upper storeys requires scaffolding at 3-6m working height. Workers access scaffold platforms to fix, measure, and cut cladding at height. Fall from scaffold is the primary catastrophic risk.)
- Work in area with contaminated/flammable atmosphere (Cutting fibre cement products generates respirable crystalline silica (RCS) dust which creates a hazardous atmosphere in the immediate work zone. Workplace exposure standard 0.05 mg/m³ TWA. Since 1 September 2024, strengthened crystalline silica regulations apply nationally.)
Australian Standards Referenced
National Guidance Documents
- Safe Work Australia - Model Code of Practice: Construction Work
- Safe Work Australia - Model Code of Practice: Preventing Falls in Housing Construction
- Safe Work Australia - Model Code of Practice: Managing the Risk of Falls at Workplaces
- Safe Work Australia - Guide to Scaffolds and Scaffolding Work
- Safe Work Australia - Crystalline Silica and Silicosis Information
- Safe Work Australia - Model Code of Practice: Hazardous Manual Tasks
- Safe Work Australia - Model Code of Practice: Managing Noise and Preventing Hearing Loss at Work
Who Needs This SWMS?
This template is designed for the following trades and roles performing external cladding installation work.
Frequently Asked Questions
Can you dry cut fibre cement cladding?
No. Since 1 September 2024, strengthened national regulations prohibit uncontrolled dry cutting of fibre cement and other silica-containing products with power tools. All power saw cutting of fibre cement must use wet cutting with continuous water supply to the blade. Alternatives include fibre cement shears (minimal dust) and scoring and snapping for thin sheets. The workplace exposure standard for respirable crystalline silica is 0.05 mg/m³ TWA, and dry cutting exceeds this within minutes.
What scaffold is required for cladding installation?
For cladding work above 2m, scaffolding with full guardrail protection is required. The scaffold must comply with AS/NZS 1576, with guardrails at 900-1100mm height, mid-rails, and 150mm toe boards. For scaffold platforms above 4m, a licensed scaffolder must erect, modify, and dismantle the scaffold. The gap between the scaffold and building face should not exceed 225mm to prevent falls between scaffold and wall.
What PPE is required for fibre cement cladding installation?
Minimum PPE for fibre cement work includes: P2/N95 respirator (AS/NZS 1716) during cutting, drilling, and sanding; impact-rated safety glasses (AS/NZS 1337); Class 5 hearing protection for power tool use; steel cap boots with puncture-resistant soles; hard hat when below scaffold; cut-resistant gloves for sheet handling (removed for power tool operation); and sun protection for outdoor work.
What are the health risks of cutting fibre cement?
Cutting fibre cement generates respirable crystalline silica (RCS) dust, which causes silicosis (irreversible lung scarring), lung cancer, chronic obstructive pulmonary disease (COPD), and kidney disease. These are serious and often irreversible conditions. The workplace exposure standard is 0.05 mg/m³ TWA (8-hour average). Workers regularly cutting fibre cement should be enrolled in a health monitoring program including lung function tests.
How do you safely handle cladding sheets in wind?
Large cladding sheets act as sails and should not be handled at height in wind gusts exceeding 30 km/h. Use a gin wheel or scaffold hoist to lift sheets to height rather than carrying up ladders. Always use two-person handling for sheets over 2.4m. Secure sheets on scaffold platforms immediately after lifting. Monitor wind conditions throughout the day and be prepared to stop sheet handling if conditions change.
Do carpenters need specific training for cladding installation?
Yes. Carpenters installing external cladding should hold a Certificate III in Carpentry (CPC30220) which includes the unit CPCCCA3024A - Install and Finish Exterior Cladding. Working at Heights training (RIIWHS204E) is required for scaffold work above 2m. Silica dust awareness training is required for workers cutting fibre cement products. A White Card is required for all construction site work.
What type of nail gun should be used for cladding?
Sequential trigger cladding nailers only. Contact/bump fire triggers are prohibited. Use stainless steel or galvanised nails to prevent corrosion staining on cladding. Nail type, length, and spacing must comply with the cladding manufacturer's fixing specifications. Pre-drill fibre cement where required to prevent cracking. Apprentices may only use nail guns under direct supervision.
What hazards does this SWMS template cover?
This template covers seven key hazards: falls from scaffolding and height, respirable crystalline silica from fibre cement cutting, nail gun injuries, circular saw and power tool injuries, manual handling of large cladding sheets in wind, falling objects from scaffold, and UV/heat exposure for outdoor work. Each hazard includes a full risk assessment with initial and residual risk ratings and a complete hierarchy of controls.
Is weather monitoring required during cladding work?
Yes. Wind speed must be monitored throughout the day. Stop handling large cladding sheets when gusts exceed 30 km/h and all scaffold work when gusts exceed 40 km/h. Check UV index and temperature forecast before starting - implement heat stress controls when temperature exceeds 35°C. Rain makes scaffold platforms slippery - consider stopping work in wet conditions. Cladding sealants may not cure properly in rain.
What are the expansion gap requirements for fibre cement cladding?
Fibre cement expands and contracts with moisture and temperature changes. Manufacturer specifications (e.g., James Hardie Technical Guides) specify minimum expansion gaps at sheet edges, around windows and doors, and at abutments. Typical gaps are 3-6mm depending on product and joint type. Gaps are sealed with flexible exterior-grade sealant. Incorrect gaps cause cracking, buckling, and warranty voidance. Always follow the specific manufacturer's installation guide.
