SWMS Template

Irrigation System Installation

7 Hazards/18 Steps/8 PPE/5 min
PDFDownload Your SWMS
First SWMS Free — No Credit Card

Installation of irrigation systems including trenching for pipe runs, PVC solvent welding, poly pipe connections, sprinkler and dripper head installation, solenoid valve setup, controller programming, pump connections, and backflow prevention device installation. Covers residential and commercial irrigation systems including spray irrigation, drip irrigation, subsurface irrigation, and combination systems. Includes controls for trench excavation (200-400mm typical depth, deeper for main line runs), underground services strike (BYDA mandatory), PVC solvent cement chemical hazards (MEK/THF solvents, flammable vapours, CNS depression, potential liver/kidney damage), electrical connections for mains-powered controllers and solenoids, manual handling of pipe bundles and heavy fittings, powered mobile plant operation (pipe trencher, mini excavator), UV exposure from full outdoor work, and noise exposure from trenching equipment. Pre-filled hazards, controls, and risk ratings.

Built for:Irrigation ContractorsIrrigation InstallersReticulation Specialists+7
70+ templatesPDF & DOCXAustralian WHS

What's In Your SWMS

01

7 Hazards & Controls

Already done for you
Risk

Electrocution, death, gas explosion, severe burns, flooding, service disruption, prosecution, litigation costs, site suspension

What to do about it
Elimination

Where possible, minimise trenching by using surface-mounted components. Use existing service corridors where available.

Substitution

Use subsurface drip irrigation where feasible instead of shallow trenching for lateral lines.

Isolation

Mark all located services with paint and pegs. Establish exclusion zones around identified services.

Engineering
  • BYDA (Before You Dig Australia) enquiry MANDATORY before any trenching - submit at www.byda.com.au or call 1100
  • Wait minimum 3 business days for BYDA response - do not trenching while awaiting response
  • Use underground service locator (CAT and Genny) to verify service positions on site
  • Hand dig within 500mm of any located service - no mechanical trenching in safe zones
  • Pothole (vacuum excavation) to physically verify depth and position of critical services
Administrative
  • BYDA enquiry must be submitted and plans received BEFORE any trenching begins
  • Review all BYDA plans at toolbox talk - identify service types, locations, and depths
  • Mark service locations on ground with paint matching BYDA colour codes (white-electricity, yellow-gas, blue-water, red-sewer, orange-comms, green-stormwater)
  • Brief all workers on safe digging procedures and service locations
  • If unidentified service encountered during trenching - STOP WORK immediately
  • Contact asset owner if any service is exposed or damaged - report immediately
  • Keep BYDA plans on site for entire duration of works
  • Use service locator to verify positions if BYDA plans show services in work area
PPE

Non-conductive safety footwear. Insulated gloves if working near suspected electrical services.

02 Work Procedure

18-Step Work Procedure

Step-by-step procedure
1
Site arrival, induction, and hazard assessment
2
Review BYDA plans and locate underground services
Underground Services Strike
3
Review irrigation design plan and mark out pipe runs
4
Set out sprinkler and dripper positions
03 Equipment & PPE

Equipment & PPE

Equipment (15)

  • Pipe trencher (walk-behind or tractor-mounted ditch witch)

    Walk-behind trenchers for narrow irrigation lines typically 10-15cm wide, 30-40cm depth. Cutting width 150-300mm depending on model. Engine power 5-10kW. Noise level 90-100 dB(A). Operator must have trencher operation experience.

  • PVC pressure pipe and fittings

    Main line and lateral lines: Class 1 (1000 kPa), Class 2 (1250 kPa), or Class 3 (1500 kPa) depending on water pressure. Sizes 16-75mm typical. Include tees, elbows, couplings, adapters. SWR (sewer) PVC not suitable for pressurised systems.

  • Polyethylene (poly) pipe and fittings

    For lateral lines and drip zones: 13-20mm typical. Lower pressure rating than PVC (suitable for 200-400 kPa zones). Flexible for curved layouts. Includes insert fittings, barbed connectors, compression fittings.

  • PVC solvent cement and primer (for PVC joining)

    MEK (Methyl Ethyl Ketone) or THF (Tetrahydrofuran) based solvents. Flammable, volatile, CNS depressant. Primer (typically acetone-based) required before gluing. Keep away from sparks/flames. Apply in well-ventilated areas only.

PPE (8)

  • Safety glasses or gogglesAS/NZS 1337

    Essential during PVC pipe cutting and trenching for protection against debris and PVC particles. Goggles preferred during solvent cement application for splash protection.

  • Hearing protection (Class 4 minimum)AS/NZS 1270

    Mandatory during pipe trencher operation (90-100 dB(A)) and mini excavator use (80-95 dB(A)). Earplugs or earmuffs acceptable. Continuous exposure over 85 dB(A) causes permanent hearing loss.

  • Safety boots (steel cap, non-slip)AS/NZS 2210.3

    Steel cap essential for dropped pipes and fittings protection. Non-slip sole for wet, muddy trench conditions and underground conditions.

  • Work gloves (solvent-resistant)AS/NZS 2161

    Leather or synthetic gloves for pipe handling. Solvent-resistant gloves (nitrile or neoprene) required for PVC solvent cement work. Replace if gloves become saturated with solvent.

04 Training & Emergency

Training & Emergency

Competency Requirements

  • Construction Induction Card (White Card)training

    Required for all workers on construction sites

  • Irrigation/Landscaping Experiencetraining

    Demonstrated experience in irrigation system installation including pipe laying, solvent joining, sprinkler installation, and controller setup. Entry-level workers should be under supervision of experienced installer.

  • Pipe Trencher Operation Competencytraining

    If using pipe trencher for irrigation line installation, operator must have demonstrated competency in trencher safe operation, blade control, and hazard awareness. Training recommended through equipment hire company or registered trainer.

  • BYDA (Before You Dig) Awarenesstraining

    Understanding of BYDA process, plan interpretation, service colour codes, safe digging within identified service zones. All workers involved in trenching must be briefed.

  • Mini Excavator Operation (RIIMPO320F)

    Required if mini excavator used for main line trenching. Unit of competency RIIMPO320F from a Registered Training Organisation (RTO). Not required if pipe trencher or hand digging only.

  • Licensed Electrician (for Mains Electrical Work)

    Required for mains-powered (230V AC) controller and solenoid electrical connections. Do not attempt mains electrical work without proper qualifications. Licensed electrician must verify compliance with Australian electrical standards.

  • First Aid Certificate

    Recommended for at least one team member. HLTAID011 Provide First Aid. Important given solvent exposure, heat stress, and electrical hazards.

  • PVC Solvent Cement Safety Training

    Training on hazards of PVC solvent cement (MEK/THF), proper application technique, ventilation requirements, PPE, and safe storage. Recommended if extensive PVC solvent welding required.

Emergency Procedures

  • UNDERGROUND SERVICE STRIKE (Electrical): Do NOT touch damaged cable. Move all workers clear immediately. Call 000 if sparking or fire hazard. Contact electricity distributor emergency line (number on BYDA plans) immediately. Do not resume work until service made safe by asset owner.

  • UNDERGROUND SERVICE STRIKE (Gas): Evacuate area immediately - minimum 50m radius. Do not use mobile phones or any ignition sources in vicinity. Call 000. Contact gas distributor emergency line (number on BYDA plans) immediately. Do not attempt to stop leak or re-enter area.

  • SOLVENT CEMENT INHALATION / CNS DEPRESSION: If worker becomes confused, dizzy, or shows signs of CNS depression during solvent work, move to fresh air immediately. Sit down, monitor breathing. If confusion, loss of consciousness, or difficulty breathing, call 000 immediately. Inform paramedics of solvent exposure.

  • + 3 more included in your SWMS

Everything above, included in your SWMS document.

Get This Template

Writing a SWMS from scratch?

That's 2-4 hours of research, formatting, and compliance checking.

We've already done it — pick your template and download.

Or just do this:

1
Pick Your Template
Pre-filled hazards, controls, and PPE.
2
Add Your Details
Business name, site address, workers.
3
Download & Go
PDF or DOCX. Hand it to your PC.
PDF
SWMS Template
Irrigation System Installation
7 Hazards & Controls
18 Work Procedure Steps
8 PPE Requirements
Emergency Procedures
Ready to download
PDFDOCX
$29
/month — unlimited SWMS
  • Unlimited documents
  • All 70+ templates
  • Instant PDF & DOCX
  • Cancel anytime
Get Your SWMS PDF
First SWMS Free — No Card Needed

High-Risk Construction Work Categories

Under Australian WHS Regulations (Section 291 - High Risk Construction Work; Chapter 4 Part 4.4 - Hazardous Manual Tasks; Chapter 7 Part 7.2 - Noise; Chapter 4 Part 4.3 - Management of hazardous substances), this work is classified as high-risk due to:

  • Involves use of powered mobile plant (Pipe trencher (walk-behind or tractor-mounted) for digging irrigation lines. Mini excavator for main line runs and complex terrain. Mini loader for moving pipe bundles and aggregate materials.)
  • Work on or near energised electrical installations (Trenching may encounter underground electrical cables during pipe run installation. Electrical connections required for mains-powered irrigation controllers and solenoid valves. BYDA enquiry mandatory before trenching.)
  • Work on or near pressurised gas mains or piping (Trenching for irrigation systems may encounter underground gas services. BYDA enquiry mandatory. Hand dig within 500mm of located gas mains.)

Australian Standards Referenced

AS/NZS 1337:2020 - Eye protection
AS/NZS 1270:2002 - Hearing protectors
AS/NZS 1716:2012 - Respiratory protective devices
AS/NZS 2161:2016 - Protective gloves for occupational use
AS/NZS 2210.3:2019 - Safety footwear
AS/NZS 4602.1:2011 - High visibility safety garments
AS/NZS 3500.2:2021 - Water supply and sewerage - Installation - Water services
AS 2033:2016 - Plimsoll mark and loadline mark for ships

Who Needs This SWMS?

This template is designed for the following trades and roles performing irrigation system installation work.

Irrigation ContractorsIrrigation InstallersReticulation SpecialistsLandscapersLandscape ContractorsGarden Maintenance WorkersPlumbers IrrigationSprinkler System TechniciansSite Preparation WorkersOutdoor Living Installers

Frequently Asked Questions

Do I need a BYDA enquiry before installing irrigation?

Yes. Before You Dig Australia (BYDA) enquiry is mandatory before any trenching for irrigation line installation. Submit a free enquiry at www.byda.com.au or call 1100 at least 3 business days before planned trenching. BYDA plans identify underground electrical, gas, water, sewer, and telecommunications services. Failure to obtain BYDA plans can result in service strikes, electrocution, gas explosion, and prosecution.

What is the proper water pressure for irrigation systems?

Typical irrigation operating pressures are 200-350 kPa (2-3.5 bar). Pop-up spray heads typically require 250-350 kPa. Drip irrigation systems operate at lower pressure (20-40 kPa) and require pressure regulators if main line pressure is higher. Always match pipe and fitting pressure ratings (Class 1 minimum 1000 kPa, Class 2 minimum 1250 kPa) to system requirements with safety factor.

Can I join PVC pipes with solvent cement safely?

PVC solvent cement can be used safely with proper precautions: work outdoors only in well-ventilated areas, never in trenches or enclosed spaces, wear P2 respirator with organic vapour filter, wear gloves and goggles, apply cement to clean dry surfaces only, allow proper cure time (10-15 minutes) before pressurising, store solvent away from ignition sources (flammable), keep container sealed when not in use. Do not inhale vapours. If dizziness occurs, move to fresh air immediately.

What depth should irrigation trenches be?

Main line and lateral lines for above-ground irrigation typically require 200-300mm trenching depth. Main line should be 300-400mm for frost protection if freezing climate. Subsurface drip irrigation trenches can be 200-600mm depending on plant root depth. Always locate underground services before trenching - BYDA mandatory.

How do I prevent soil clogging of drip emitters?

Install a filter unit on the main water supply before the drip line (200-400 micron screen filter typical). Clean or backflush filter regularly (weekly in sandy soil, monthly in better soil). Use filtration and pressure regulation specifically designed for drip systems. Drip systems are more sensitive to water quality than spray systems.

What is a backflow prevention device and why is it required?

Backflow prevention device prevents irrigation water flowing back into the mains water supply, which could contaminate potable water. Australia requires backflow prevention at every irrigation system connection to mains water. Dual check valve is typical for low-hazard systems. Reduced pressure zone (RPZ) valve required for higher-hazard systems per local plumbing code. Backflow device must be installed at mains connection point before all irrigation components.

Can I install a mains-powered (230V) controller myself?

No. Installation of mains-powered (230V AC) electrical controllers and solenoid circuits must be performed by a licensed electrician. Do not attempt DIY mains electrical work - electrocution risk is severe. Licensed electrician must verify compliance with Australian electrical standards and install RCD (residual current device) protection on outdoor circuits. Battery-powered or solar controllers can be installed by general irrigation contractors.

What PPE is essential for irrigation installation?

Minimum PPE includes: safety glasses (debris and solvent splash protection), hearing protection during trencher/excavator operation, steel cap non-slip boots (pipe crush and mud protection), work gloves (pipe handling and solvent resistance), P2 respirator with organic vapour filter for PVC solvent cement work, sun protection (wide-brim hat, long sleeves, SPF 50+ sunscreen), and knee pads for ground-level sprinkler installation.

How do I test the irrigation system for leaks?

Pressurise system to normal operating pressure (typically 250-300 kPa). Inspect all pipe joints and connections for leaks. Listen for hissing sounds indicating leaks. Check solvent cement joints and compression fittings for seepage. Tighten any loose connections. Maintain pressure for minimum 30 minutes - if pressure drops, there is a leak. Do not exceed rated pressure of pipes and fittings.

What maintenance is needed for irrigation systems?

Regular maintenance includes: monthly filter cleaning/backflushing (if drip system), seasonal controller adjustment (reduce watering in winter, increase in summer), annual solenoid valve inspection and cleaning, check for leaks and damage after storms, winterisation in freezing climates (drain system and remove solenoids), and drip line flushing to remove sediment.

What hazards are specific to irrigation installation?

Key hazards are: underground services strike during trenching (BYDA mandatory), PVC solvent cement chemical exposure (flammable, toxic vapours, CNS depression), manual handling of pipes and components, trencher and excavator operation (noise 90-100 dB(A), struck-by hazards), UV and heat exposure from outdoor work, electrical hazards from mains-powered controllers (licensed electrician required), and noise-induced hearing loss.
